PR electronics 2224 - DC Voltage Input

10 2224V103-UK
Wiring diagrams for DC voltage input
Double valve control (A/B valves) from a 0...1 VDC
input signal.
DIP-switch programming:
Function 1 or
Function 2.
Single valve control from a 0...1 VDC input signal.
DIP-switch programming:
Function 1.
Double valve control (A/B valves) from a -10...+10
VDC input signal.
DIP-switch programming:
Function 1 or
Function 2.
