9202MCM101 5
9202 Process Parameter List
Parameter
Name
No.
Register
Address
Register
Size
Read/
Write
Type Description Values
CONFIGURATION
STATUS
1000 1000 2 RO INTEGER
Shows the device configuration
according to the SIL setting.
“FAIL” No valid configuration has been received
“OPEN” Actual configuration is NOT locked (non-SIL)
“LOCK Actual configuration is locked (SIL)
“INIT” Initial status after a powerup/reset until a con-
figuration has been received
ERROR STATUS 1001 1002 1 RO INTEGER
Status of common errors for
the device.
CRC ERROR: bit 0 = 1
CALIBRATION ERROR: bit 1 = 1
CONFIGURATION ERROR: bit 2 = 1
READ ERROR: bit 3 = 1
WRITE ERROR: bit 4 = 1
SUPPLY ERROR: bit 5 = 1
CPU ERROR: bit 6 = 1
FLASH/RAM/CRC ERROR: bit 7 = 1
MEASURE
STATUS
1002 1003 1 RO
UNSIGNED
INTEGER
Shows the device measurement status.
CH1 ENERGIZED: bit 0 = 1
CH1 BREAK DETECT: bit 1 = 1
CH1 SHORT DETECT: bit 2 = 1
CH1 DIRECTION: bit 3 = 1
CH2 ENERGIZED: bit 4 = 1
CH2 BREAK DETECT: bit 5 = 1
CH2 SHORT DETECT: bit 6 = 1
CH2 DIRECTION: bit 7 = 1
CHANNEL 1
STATUS
1004 1005 1 RO
UNSIGNED
INTEGER
Shows the status ofchannel 1.
FREQ. ABOVE 1Hz: bit 0 = 1
FREQ. ABOVE 5Hz: bit 1 = 1
CHANNEL 2
STATUS
1006 1007 1 RO
UNSIGNED
INTEGER
Shows the status ofchannel 2.
FREQ. ABOVE 1Hz: bit 0 = 1
FREQ. ABOVE 5Hz: bit 1 = 1
MEASURE
CONTROL
1007 1008 1 R/W
UNSIGNED
INTEGER
Enables simulation of Error and Rail
signals. Actual setting of the signals is
controlled by OUTPUT STATE.
RESERVED Must be set to 0 bit 0
RESERVED Must be set to 0 bit 1
Error out simulation,
set by OUTPUT STATE bit 2 = 1
Rail signal simulation,
set by OUTPUT STATE bit 3 = 1
RESERVED Must be set to 0 bit 4...7
OUTPUT STATE 1008 1009 1 R/W
UNSIGNED
INTEGER
Shows status of Used to set value of
the simulated process.
RESERVED Must be set to 0 bit 0...3
Error out simulation value
(1=OFF, 2=ON) bit 4
Rail Signal simulation value
(1=OFF, 2=ON) bit 5
RESERVED Must be set to 0 bit 6...7
TIMEOUT
COUNTER
1009 1010 1 R/W
UNSIGNED
INTEGER
Time-out counter which resets various
bits in MEASURE CONTROL upon over-
flow and is automatically set to 133.
Decrements once every 0.075 s.
Range: 0...255
