PR 4131 - Connections; Supply; Inputs; Outputs

41 42 43 44 41 42 43 44 41 42 43 44 41 42 43 44
41 42 43 44 41 42 43 44 41 42 43 44 41 42 43 44
41 42 43 44 41 42 CJC 44
31 32 33
21 22 23 24
- +
- +
- +
-
+
- +
Tx
R1 R2
16 4131V104-UK
CONNECTIONS
Inputs:
Outputs:
Supply:
Relays
RTD, 3- / 4-wire
Resistance,
3- / 4-wire
Voltage
Potentiometer
Current2-wire transmitter
RTD, 2-wire Resistance, 2-wire
TC, internal
CJC sensor
*TC, CJC
connector
* Order separately:
CJC connector 5910
