PR 5114 - Page 11

5114V107-UK 9
Accuracy, the greater of the general and basic values:
Auxiliary supplies:
Reference voltage ................................................... 2.5 VDC ±0.5% / 15 mA
2-wire supply (pin 44...42 and 54...52) .......... 28...17.1 VDC / 0...20 mA
Max. wire size ............................................................ 1 x 2.5 mm
2
stranded wire
Screw terminal torque ........................................... 0.5 Nm
Relative humidity..................................................... < 95% RH (non-cond.)
Dimensions (HxWxD) .............................................. 109 x 23.5 x 130 mm
DIN rail type ............................................................... DIN 46277
Protection degree .................................................... IP20
Weight .......................................................................... 225 g
EMC immunity influence .................................................. < ±0.5% of span
Extended EMC immunity:
NAMUR NE 21, A criterion, burst ................................. < ±1% of span
General values
Input type
Absolute
accuracy
Temperature
coefficient
All
≤ ±0.05% of span ≤ ±0.01% of span / °C
Basic values
Input type
Basic
accuracy
Temperature
coefficient
mA
≤ ±4 µA ≤ ±0.4 µA / °C
Volt
≤ ±10 µV ≤ ±1 µV / °C
RTD
≤ ±0.2°C ≤ ±0.01°C / °C
Lin. resistance
≤ ±0.1 Ω ≤ ±10 mΩ / °C
TC type:
E, J, K, L, N, T, U
≤ ±1°C ≤ ±0.05°C / °C
TC type: B, R, S,
W3, W5, LR
≤ ±2°C ≤ ±0.2°C / °C
