PR 5114 - Page 14

12 5114V107-UK
EEx / I.S. approval (5114B):
DEMKO 99ATEX124571 ....................................... II (1) GD
[EEx ia] IIC
Applicable in .............................................................. Zone 0, 1, 2, 20, 21 or 22
Ex / I.S. data for 5114B, all types:
Terminal 31, 32, and 33
U
m
.................................................................................. : 250 V
Ex / I.S. data for 5114 B1 (channel 1 for 5114B3):
Terminal 41, 42, 44 to 43 (51, 52, 54 to 53)
U
o
................................................................................... : 7.5 VDC
I
o
..................................................................................... : 6.0 mADC
P
o
.................................................................................... : 11.25 mW
L
o
.................................................................................... : 200 mH
C
o
.................................................................................... : 6.0 μF
Ex / I.S. data for 5114 B2 (channel 2 for 5114B3):
Terminal 44 to 41 (54 to 51)
U
o
................................................................................... : 28 VDC
I
o
..................................................................................... : 87 mADC
P
o
.................................................................................... : 0.62 W
L
o
.................................................................................... : 4.2 mH
C
o
.................................................................................... : 0.08 μF
Terminal 42, 43 to 41 (52, 53 to 51)
U
o
................................................................................... : 7.5 VDC
I
o
..................................................................................... : 6.0 mADC
P
o
.................................................................................... : 11.25 mW
L
o
.................................................................................... : 200 mH
C
o
.................................................................................... : 6.0 μF
Marine approval:
Det Norske Veritas, Ships & Offshore ............. Standard for Certification No. 2.4
Ex / I.S. approval:
ATEX 2014/34/EU ................................................... DEMKO 99ATEX124571
EAC Ex TR-CU 012/2011 ..................................... RU C-DK.GB08.V.00410
Observed authority requirements:
EMC ................................................................................ 2014/30/EU
RoHS ............................................................................. 2011/65/EU
LVD ................................................................................. 2014/35/EU
EAC ................................................................................. TR-CU 020/2011
Of span = Of the presently selected range
