Auxiliary supply:
2 wire supply, pin 46...45 ............................. 25...15 VDC / 0...20 mA
Vibration ...................................................................... IEC 60068-2-6 Test FC
2...13.2 Hz ........................................................... ±1 mm
13.2...100 Hz ..................................................... ±0.7 g
Wire size, pin 41...46 max. .................................. 1 x 1.5 mm
2
stranded wire
Wire size, others max. ........................................... 1 x 2.5 mm
2
stranded wire
Relative humidity..................................................... < 95% RH (non cond.)
Dimensions (HxWxD) .............................................. 48 x 96 x 120 mm
Cutout dimensions .................................................. 44.5 x 91.5 mm
Protection degree (mounted in panel) ............ IP65 / Type 4X, UL50E
Weight .......................................................................... 230 g
RTD, linear resistance and potentiometer input:
Basic values
Input
type
Basic
accuracy
Temperature
coefficient
mA ≤ ±4 µA ≤ ±0.4 µA / °C
Volt ≤ ±20 µV ≤ ±2 µV / °C
Pt100 ≤ ±0.2°C ≤ ±0.01°C / °C
Linear resistance ≤ ±0.1 Ω ≤ ±0.01 Ω / °C
Potentiometer ≤ ±0.1 Ω ≤ ±0.01 Ω / °C
TC type:
E, J, K, L, N, T, U ≤ ±1°C ≤ ±0.05°C / °C
TC type: R, S, W3,
W5, LR ≤ ±2°C ≤ ±0.2°C / °C
TC type: B
85...200°C
≤ ±4°C ≤ ±0.4°C / °C
TC type: B
200...1820°C
≤ ±2°C ≤ ±0.2°C / °C
Input
type
Min.
value
Max.
value Standard
Pt10...Pt1000
Ni50...Ni1000
Cu10...Cu100
Lin. R
Potentiometer
-200°C
-60°C
-200°C
0 Ω
10 Ω
+850°C
+250°C
+260°C
10000 Ω
100 kΩ
IEC 60751
DIN 43760
α = 0.00427
-
-
EMC immunity influence .................................... < ±0.5% of readout
