FEED BOX PARTS
No. Code Qty. Name No. Code Qty. Name
1 20102 1 Feed box 37 20202 1 Gear
2 20234 1 Pinion shaft 38 20201 1 Speed lever
3 20243 1 Spindle stroke dial 39 1 Steel ball 8
4 20242 1 Clutch bushing set 40 2 Retainer ring 12
5 20241 1 Backing pin 41 1 Spring
6 1 Pin 6×12 42 1 Screw M6×20
7 20247 1 Ball head pin 43 20303 1 Plate
8 2 Pin 4×10 44 20206 1 Knurled pin
9 20239 1 Square thread set 45 20204 1 Limited screw
10 20240 1 Square thread nut 46 20233 1 Worm shaft
11 20244 1 Handle body 47 20306 1 Bush
12 20245 2 Washer 48 1 Key
13 20203 1 Handle 49 20228 1 Gear
14 20237 1 Clutch key base set 50 20229 1 Gear
15 20236-2 1 Bush 51 20230 1 Gear
16 20236-1 1 Worm gear 52 20106 1 Bush
17 20231 2 Clutch screw set 53 20227 1 Worm cover
18 20235 2 Screw 54 20305 1 Bush
19 20232 2 Spring 55 1 Screw M6×12
20 20223 1 ⅡShaft 56 2 ScrewM6×25
21 2 Bearing 6003 57 20107 1 Bushing
22 20215 1
Change gear lever set
58 20226 1 Mirco feed dial
23 20220 1 spring 59 20105 1 Hand wheel
24 20222 1 Pull key 60 1 Handle
25 2 Pin 2×10 61 1 Screw M5×8
26 20304 1 Worm gear 62 1 Locked screw M5×12
27 1 Key 8×16 63 20307 1 "0"Scale
28 20217 4 Bushing 64 20301 2 Knob
29 20218 1 Gear 65 2 Rivet 2×5
30 20219 1 Gear 66 1 Oil cup
31 20221 1 Gear 67 20246 1 Screw
32 20216 1 Bushing bracket 68 20308 2 Pin
33 2 ScrewM4×6 69 1 Locked handle
34 1 Retainer ring 35 70 4 ScrewM6×50
35 2 Key 4×8 71 2 Taper pin6x60
36 3 Screw M4×12
