ADDITIONAL SAFETY RULES FOR MILL DRILL
1.BE SURE drill bit or cutting tool is securely locked in the chuck.
2.BE SURE chuck key is removed from the chuck before turning on power.
3.Adjust the table or depth stop to avoid drilling into the table.
4.SHUT OFF the power ,remove the drill bit or cutting tool, and clean the
table before leaving the machine.
5.CAUTION. When practical , use clamps or a vise to secure workpiece to
keep the workpiece from rotating while the drill bit or cutting tool.
6.WARNING: FOR Your Own Safety Don't wear gloves when operating a
mill/drill.
SPECIFICATIONS:
WARNING:CHANGE SPEED ONLY WHEN MACHINE IS
STOPPED
WARNING:SPINDLE AUTOMATIC FEED FUNCTION IS
FORBIDDEN WHEN SPEED ABOVE 3000 rpm!
Drilling capacity
cast iron 32mm
mild steel 25mm
Face mill capacity 80mm
End mill capacity 32mm
Working table size 1000mm×240mm
Working table cross travel 300mm
Working table longitudinal travel 600mm
T-Slot size 14mm
Head tilt left right 90°
Spindle taper (option) MT3 or MT4 R8 or ISO40
Max distance spindle to table 50-550mm
Spindle stroke 125mm
Spindle auto-feed speed 0.10/0.18/0.26mm/r
L
H
-5000
verall dimension
450mm×1000mmm×2100mm
