Precision Power PC PRO10 - Sealed Speaker Diagram

SEALED ENCLOSURE
L
W
D
Mounting hole diameter
Foam seal gasket
Subwoofer
10-24 Allen head bolt
10-24 T-nut
Internal dimensions should be calculated to determine the correct box volume.
Be sure to allow for speaker displacement and extra bracing (if used).
Sealed speaker diagram
3
