PORTED ENCLOSURE
L
W
D
Mounting hole diameter
10-24 T-nut
Foam seal gasket
Subwoofer
10-24 Allen head bolt
Port
Internal dimensions should be calculated to determine the correct box
volume. Be sure to allow for speaker displacement, extra bracing (if used),
and port displacement. It may be necessary to angle the port to fit your
design.To calculate volume of the port: Radius
2
x 3.14 x Length of port.
5
