SPECIFICATIONS
PC740.5 PC1000.1
Channels 5 1
RMS Power @ 4Ω, 14.4V 70W X 4, 275W X 1 -
RMS Power @ 2Ω, 14.4V 100W X 4, 450W X 1 1000W X 1
RMS Power @ 4Ω Bridged 200W X 2 -
RMS Power @ 1Ω, 14.4V - 1000 x 1
Total Harmonic Distortion (4Ω power) 0.02% 0.02%
Frequency Response 15-50KHz 15-200Hz
Input Sensitivity 200mV-9V 200mV-9V
Signal-to-Noise Ratio (4Ω power) 104dB 102dB
Damping Factor (100Hz, 4Ω) >1400 >2400
Dimensions: H X W X L 2” X 10” X 16.75” 2.3” X 10” X 16.5”
Channels 1&2 HPF (12dB Slope) 15-4KHz -
Channels 1&2 LPF (12dB Slope) - 50-200Hz
Channels 3&4 HPF (12dB Slope) 15-500Hz -
Channels 3&4 LPF (12dB Slope) 50-4KHz -
Channels 5 LPF (12dB Slope) 50-200Hz -
Bass Boost 0-12dB
(CH5 only)
0-12dB
30-90Hz
Subsonic Filter Slope 12dB 15-50Hz 15-50Hz
Phase Control 0 or 180/switch 0 or 180/variable
Remote Gain Control Included Included
External Fuse Required 100 150
