7
Troubleshooting Procedures
Problem Procedure
9.02 The following is a list of the tools and
instruments required to perform the
procedures outlined in the Troubleshooting
Procedures table.
Suggested Tools:
Phillips Screwdriver
7/16" Socket or adjustable wrench
Ohmmeter
DC Voltmeter
AC Voltmeter
5VDC Power Supply
Nut Driver 11/32"
9.0 TROUBLE SHOOTING
WARNING
SERVICE SHOULD BE PERFORMED BY A
QUALIFIED TECHNICIAN. BEFORE REPLACING ANY
ELECTRICAL OR MECHANICAL COMPONENTS,
UNPLUG THE LINE CORD. IF ELECTRICAL POWER
IS REQUIRED FOR SERVICE, USE EXTREME CARE.
9.01 Refer to Troubleshooting Procedures Table
(9.03 through 9.06) for troubleshooting
information on the baths. This table provides
the basic information required to repair the
bath.
9.03 No Heat
1. Verify that setpoint temperature is greater than the actual
water temperature.
2. Check temperature probe.
A. Disconnect unit from electrical supply.
B. Disconnect temperature probe connector J5 from Control
Board.
C. Place 5 volt DC between Pins 1 & 3 on temperature probe
connector.
D. Place a voltmeter between Pins 2 & 3 on temperature
probe connector. Place the temperature probe in a bath
of known temperature. Verify that the output voltage of
the temperature probe approximately corresponds to the
values in the table below.
Degrees Centigrade vs. Output Voltage of Temperature
Probe
Temp °C Vout Temp °C Vout
0 320mV 60 1.400V
10 500mV 70 1.580V
20 680mV 80 1.760V
30 860mV 90 1.940V
40 1.040V 99.9 2.218V
50 1.220V
To Next Page
