Precision TBS4500PRCGY - Assembly

Assembly Insbuctlons
Tools Requlred lôr Assembly
Minimum
(2) 7/16” Wrenches
(1) Hammer
Remove from Carton
Rernove all pfl and hardware packages from the carton. Lay out all pfl and hardware and
identify them using the illustrations on pages 2 and 3.
Assembly
Note: Loosely tlghten nuts and bolts first. Fully tlghten when die sireader Is completely
assembied.
1. AttachtheTow BartothecenterholeoftheCross Brace, using a 1/4”x 1-1/2 Hex Head Boltand
a 1/4”NylockNutSeeFlgurel.
Tow Bar
114’ xl
112’ Hex
cme
Bmca
Flaure 1
~~_— 114”
er Nylodc
