EFX 400 Series Assembly Guide 10
3. Screw a foot into each stabilizer.
Note: Make sure the nut rests against the stabilizer.
Figure 15: Adjustable foot attachment
4. For easier access to the base mounts, lift the front of the EFX off the floor and
place a wedge of packaging cardboard beneath its base.
Figure 16: Place packaging under the EFX
5. Have your assistant hold the stabilizer (with a cable protruding from both
ends) next to the handlebar shaft and base frame while you connect the base
cable. You will hear a click when the cable is properly attached. Store excess
cable in the stabilizer frame.
Figure 17: Attach the data cable
