Precor GluteBuilder GPL551/DLE - Page 13

13
Exploded View and Parts List
Frame II ASSY
Item No. Part No. Description QTY
9.1 DLE0200
Frame Ⅱ 1
9.2 PKB3100 Large Elliptical Pipe Plug R60*120 1
9.3 PKB3200 Floor Mat 2
9.4 IN-D10135000 Limit Sleeve 1
9.5 PL380800 Buffer Pad 120*140*52 1
9.6 DQ12DY2B Flat Washer Φ13*Φ26*2 2
9.7 GB70M12*30DY20 Socket Head Cap Screw M12*30 2
9.8
YZGB290.25*20*18DS20 Hex Head Cap Screw 1/4*20 4
