Precor GluteBuilder GPL551/DLE - Page 14

14
Exploded View and Parts List
Movable Support Frame II ASSY
Item No. Part No. Description QTY
10.1 DLE0500
Movable Support FrameⅡ 1
10.2 GB2766205-2ZC3 Bearing 6205-2ZC3 2
10.3 DLE2100 Latch Shaft 1
10.4 SL70403000 Handle 1
10.5 CG50001700P170C Grip 1
10.6 C015PL2300 Limit Sleeve 1
10.7 PKB3300 Large Elliptical Pipe Plug R50*100 2
10.8 DLE08ASSY
Long Handle FrameⅡASSY 1
10.9 DLE12ASSY
Short Handle FrameⅡASSY 1
10.10 IN-D21202000V1 Aluminium Cap Φ38 1
10.11 CNLM10*25DY20NL Flat Head Cap ScrewM10*25 2
10.12 IN-D10132300V3 Aluminium Cap Φ43*Φ11*8 1
