STEP 1
Attach one Barbell Frame ASSY (#1) to Main Stand ASSY (#5), using:
one Rotating shaft 3 (#12)
two Button Head Cap Screw M12*25 (#18)
two Aluminium Cap Φ49*Φ12.5*10 (#19)
two Socket Set Screw M8*10 (#28)
Assembly
16
