Item No. Part No. Description QTY
4.1 3DAB0800 Pedal Frame 1
4.2 HF985A1700 Pipe Plug Φ42 1
Item No. Part No. Description QTY
3.1 3DAB0500 Sway Leg Frame 2 1
3.2 PKB14ASSY Plug Pin ASSY 1
3.3 PKB3300 Large Elliptical Pipe Plug R50*100 3
3.4 V39600V2 Aluminium Grip Cap Φ25.4 1
3.5 CWRVL0231900 Grip 1
3.6 V39500V2 Aluminium Grip Ring Φ25.4 1
3.7 GB2766205-2ZC3 Bearing 6205-2ZC3 2
3.8 YZGB7710-32*3.2DY2 Socket Set Screw 10-32*3.2 4
