Item No. Part No. Description QTY
4.1 D45HE0400 Front main frame 1
4.2 M02502000 Bushing Φ25.4 2
Item No. Part No. Description QTY
5.1 D45HE0600 Swing frame 1
5.2 PKB1300 Short Elastic Band Holder 1
5.3 D45HE2800 Lining Board 1
5.4 PKB3300 Large Elliptical Pipe Plug R50*100 1
5.5 BB-PL5000V1 Aluminium Cap Φ49*Φ12.5*10 2
5.6 HZ70022000 Short Barbell Casing 1
5.7 PL1301600 Buffer Pad Φ76*26 1
5.8 IN-S10111200 Limit Sleeve 2
5.9 GB2766205-2ZC3 Bearing 6205-2ZC3 2
5.10 GB70M8*15DY20NL Socket Head Cap Screw M8*15 2
5.11 GB70M10*25DY20NL Socket Head Cap Screw M10*25 1
5.12 PNLM12*25DY20NL Button Head Cap Screw M12*25 2
5.13 DQ10DY2A Flat Washer Φ11*Φ23*2 1
5.14 GB9310DY12 Spring Washer Φ10 1
