Precor GluteBuilder GPL724/D45HE - Page 14

14
Exploded View and Parts List
FOAM Frame ASSY
FOAM ASSY
Adjusting Frame ASSY
Item No. Part No. Description QTY
9.1 D45HE1000 Adjustment pipe 1
9.2 IN-D10134200 Plug J30*70 1
9.3 GB17880.5M10*19.5DS17 Rivet nut M10 1
Item No. Part No. Description QTY
20.1 IE95026400 Retainer 2
20.2 FE97026300V2 FOAM 1
Item No. Part No. Description QTY
8.1 D45HE0900 FOAM Frame 1
8.2 IF81165000 Lock Nut M10 2
