Precor GluteBuilder GPL724/D45HE - Page 26

STEP 7
1. Attach two Leg Pad (#21) to Upper Handlebar ASSY (#6), using:
eight M10*25 SHCS (#28)
eight Φ11*Φ23*2 Flat Washer (#40)
2. Attach two FOAM ASSY (#20) to FOAM Frame ASSY (#8), using:
two Cap Φ63 (#25)
two M10*25 BHCS (#35)
3. Attach one Barbell Frame ASSY (#12) to Rear Main Frame ASSY (#1), using:
one Cap Φ49 (#24)
one M12*25 BHCS (#36)
Note: Wrench Tighten Bolts.
Assembly
26
