Predator Engines 212 User Manual

Page 11
For Engine technical questions, please call 1-800-520-0882.
Horizontal Engines
Electric Start (if equipped)
1. To start a cold engine, move the Choke to the
CHOKE position.
To restart a warm engine, leave the Choke in the
RUN position.
2. Open the Fuel Valve.
3. Slide the Throttle or Speed Control Lever to 1/3
away from the SLOW position (the “turtle”).
Note: Some tools have a Speed Control Lever located
elsewhere on the tool which functions the same as
the Throttle. Use the Speed Control Lever in place
of the Throttle when the tool is so equipped.
4. Turn the Engine Switch to START.
CHOKE RUN
1
2
3
ON
OFF START
4
START

Predator Engines 212 Specifications

General

Displacement	212cc
Bore x Stroke	70mm x 55mm
Compression Ratio	8.5:1
Maximum Output	6.5 HP @ 3600 RPM
Shaft Orientation	Horizontal
Max Torque	2500 RPM
Fuel Type	Gasoline
Shaft Diameter	0.75 inches
Starting System	Recoil
Oil Capacity	0.6 liters
