Parts Lists and Diagrams
Main Parts List
Part Description Qty.
1 Hopper 1
2 Chipper Chute 1
3 Chipper Chute Flap 1
4 Flap Mounting Plate 1
5 Bolt M5x12 8
6 Lock Nut M5 10
7 Engine Mounting Plate 1
8 Screen 1
9 Front Support 1
10 Wheel 2
11 Access Panel 1
12 Cutter 1
13 Engine 1
14 Chipper Blade 2
15 Bracket 1
16 Hopper Flap 1
17 Rubber Flap 1
18 Blade Shaft 2
19 Spacer A 4
Part Description Qty.
20 Mulching Blade 8
21 Spacer B 2
22 Flat Washer Ø8 20
23 Lock Nut M8 20
24 Flange Nut M8 4
25 Bolt M8x20 4
26 Flat Washer Ø12 2
27 Cotter Pin 2.5x28 2
28 Cap Screw M5x30 2
29 Hex Bolt 5/16″-24 x 2-3/8″ 4
30 Flange Bolt M8x20 3
31 Flange Bolt M8x35 4
32 Deep Groove Ball Bearing 1
33 Thick Washer 1
34 Cap Screw 5/16″-24 x 4-7/8″ 1
35 Bolt M8x150 2
36 Lock Washer Ø8 1
37 Cap Screw M8x12 4
To Next Page
