Page 2 For technical questions, please call 1-800-520-0882. ITEM 60599
SAFETY OPERATION MAINTENANCESETUP
Table of Contents
Specifications ............................................. 2
Safety ......................................................... 3
Setup .......................................................... 6
Operation .................................................... 8
Maintenance .............................................. 12
Troubleshooting ......................................... 16
Parts Lists and Diagrams .......................... 18
Warranties ................................................. 22
Specifications
Chipper/Shredder Specifications
Chipper Chute Capacity 1-1/4″ Maximum Diameter
Chipper Dimensions 2-3/4″ x 2-3/4″ Square opening
Hopper Capacity 3/8″ Maximum Limb Diameter
Hopper Dimensions 18″ L x 14-3/4″ W
Ground Clearance 3-1/2″ At Lowest Point
Wheels 7-1/2″ Dia. x 2-1/4″ W
Engine Specifications
Displacement 212cc
Engine Type
Horizontal Single Cylinder
4 stroke OHV
69727: Meets EPA phase III and
CARB emissions standards
69730: Meets EPA phase III
emissions standards
Cooling System Forced air cooled
Fuel
Type 87+ octane unleaded gasoline
Capacity 0.9 Gallon (3.6 Liter)
Engine Oil
Type SAE
10W‑30 above 32° F
5W‑30 at 32° F or below
Capacity 20 ounces (0.6 liter)
Run Time @ 50% Load
with full tank
3 hr.
Sound Level at 22 feet 104 dB
Bore x Stroke 70 mm x 55 mm
Compression Ratio 8.5:1
Rotation viewed from PTO
(power takeoff ‑ the output shaft)
Counterclockwise
Shaft
Shaft 3/4″ x 2.43″
Keyway 3/16″ (4.76 mm)
End Tapped 5/16″ - 24 UNF
Spark Plug
Type
NGK
®
BP‑6ES
NHSP
®
/ Torch
®
F6TC
Gap 0.7 ‑ 0.8 mm
Valve Clearance
Intake 0.10 ‑ 0.15 mm
Exhaust 0.15 ‑ 0.20 mm
Speed Idle 1,800 ± 50 RPM
