Page 26 For technical questions, please call 1-800-520-0882. Horizontal Engines
68136 346cc Parts List
Part Description Qty.
1 Gasket, Cylinder Head 1
2 Cover Asm., Cylinder Head 1
3 Gasket, Cylinder Head Cover 1
4 Tube, Breather 1
5 Bolt Asm., Cylinder Head Cover 1
6 Stud 2
7 Stud 2
8 Pin 2
9 Bolt, Cylinder Head 4
10 Plug, Spark 1
11 Head Asm., Cylinder 1
12 Crankcase Asm. 1
13 Seal, Oil 1
14 Sensor, Engine Oil 1
15 Frame, Fuel Tank Installation 1
16 Plug, Rubber 1
17 Protector, Oil 1
18 Bolt 1
19 Washer_ Flat 2
20 Bolt, Drain Plug 2
21 Clip 1
22 Arm, Governor 1
23 Seal, Oil 1
24 Pin 1
25 Bolt 4
26 Bolt 2
27 Washer_ Flat 1
28 Bearing 1
29 Cover, Crankcase 1
30 Gasket, Crankcase 1
31 Plug Asm., Engine Oil 1
32 Dipstick Asm., Oil 1
33 Pin 2
34 Bolt 7
35 Bearing 1
36 Gear Asm., Governor 1
37 Seal, Oil 1
38 Bearing 1
39 Crankshaft Asm. 1
40 Shaft Asm., Balancing 1
41 Ring Set, Oil 1
42 Clip, Piston Pin 2
43 Piston 1
44 Pin, Piston 1
45 Rod, Connecting 1
46 Ring, The First 1
47 Ring, The Second 1
48 Camshaft Asm. 1
49 Valve, Exhaust 1
50 Valve, Intake 1
51 Seat, Valve Spring 1
52 Retainer, Exhaust Valve 1
53 Rotator, Valve 1
54 Guide, Seal 1
55 Tappet, Valve 2
56 Lifter Asm., Valve 2
Part Description Qty.
57 Plate Asm., Lifter Stopper 1
58 Bolt, Valve Adjusting 2
59 Rocker, Valve 2
60 Nut, Valve Adjusting 2
61 Nut, Valve Lock 2
62 Spring, Valve 2
63 Retainer, Valve Spring 1
64 Starter Asm., Recoil 1
65 Bolt 3
66 Shroud 1
67 Shroud, Cylinder Body 1
68 Bolt 1
69 Bolt 5
70 Carburetor Asm. 1
71 Gasket, Air Cleaner 1
72 Gasket, Carburetor 1
73 Plate, Carburetor Insulator 1
74 Gasket, Inlet 1
75 Nut 2
76 Cleaner, Air 1
77 Bolt 1
78 Nut 3
79 Gasket, Exhaust Outlet 1
80 Nut 2
81 Muffler Asm. 1
82 Gasket, Aux. Air Valve Flange 1
83 Valve, Muffler Aux. Air 1
84 Bolt 2
85 Tank, Fuel 1
86 Strainer, Fuel 1
87 Cover, Fuel Tank 1
88 Outlet Asm., Fuel Tank Oil 1
89 Collar 5
90 Tube, Fuel 1
91 Clamp 1
92 Nut 2
93 Valve, One Way 1
94 Hose, Fuel Vapor Rubber 1
95 Hose, Air Cleaner Rubber 1
96 Collector, Fuel Vapor 1
97 Bolt 2
98 Cover, Fuel Vapor Collector 1
99 Nut, Flywheel 1
100 Pulley,Starter 1
101 Impeller 1
102 Flywheel Asm. 1
103 Bolt 2
104 Coil, Ignition 1
105 Control Asm., Throttle 1
106 Bolt 2
107 Spring, Throttle Valve Returning 1
108 Rod, Governor 1
109 Support Asm., Governor 1
110 Nut 1
111 Bolt, Governor Support 1
112 Spring, Governor 1
