Page 6 For technical questions, please call 1-888-866-5797. ITEM 57064
SAFETY SETUP OPERATION MAINTENANCE
Functional Description
Specifications
Generator
Output
120 VAC, 60 Hz, 11.6 A, 1 Phase
1,400 Running Watts (1,800 Max. Starting Watts)
12VDC, 8.3 A
Electrical Receptacle
3-Prong, duplex NEMA #5-20 120 V
One DC Outlet 12 VDC
Engine
Displacement 98 cc
Engine Type Horizontal Single Cylinder 4 stroke OHV
Cooling System Forced air cooled
Fuel
Type 87+ octane stabilizer treated unleaded gasoline
Capacity 1.6 Gallons
Engine Oil
Type SAE
10W – 30 above 32° F
5W – 30 at 32° F or below
Capacity 0.4 Quart
Spark Plug
Type LG E6RTC
Gap 0.028” - 0.031”
Valve Clearance
Intake 0.003” - 0.0047”
Exhaust 0.005” - 0.006”
Run Time @ 50% load 9.5 hr.
The emission control system for this Generator’s Engine is warranted for standards set by the U.S. Environmental
Protection Agency and by the California Air Resources Board (also known as CARB). For warranty information,
refer to the last pages of this manual.
Components and Controls
Air
Cleaner
Starting
Handle
Fuel Cap
Fuel Valve
Control
Panel
Choke
Fuel Level Indicator
