Specifications
Generator
Output
120/240 VAC, 60 Hz, 63.3 / 31.7 A, 1 Phase
12 VDC, 8 A (nominal)
5V USB, 3.1A
7600 Running Watts
9500 Maximum Starting Watts
Receptacles
2 x GFCI NEMA #5-20R (3-prong, 120 VAC)
1 x NEMA #L5-30R (3-prong, 120 VAC)
1x NEMA #L14-30R (4-prong, 120/240 VAC)
1 x 12 VDC Two Pin Outlet
2 x USB-A Outlets
Parallel Kit Terminals
Displacement 459 cc
Compression Ratio 8.5:1
Engine Type
Horizontal Single Cylinder
4-stroke, OHV
Cooling System Forced air cooled
Fuel
Type
87+ octane, stabilizer-treated
unleaded gasoline
Capacity 6.60 Gallon / 25.00 Liter
Engine Oil
Type SAE 10W-30
Capacity 37 fl. oz.
Run Time @ 25% Load
with full tank
18.5 hr.
Sound Level at 23 feet, 25% load 67 dB
Bore x Stroke 92mm x 69mm
Spark Plug
Type BPR6ES (NGK) or equivalent
Gap 0.027"– 0.031"
Valve Clearance
Intake 0.0039"– 0.0059"
Exhaust 0.0059"– 0.0078"
Engine Speed 2560 - 3410 RPM
The emissions control system for this Engine is warranted for standards set by the
U.S. Environmental Protection Agency and by the California Air Resources Board (also known as CARB).
For warranty information, refer to the last pages of this manual.
