Page 2 For equipment technical questions, please call 1-888-866-5797. Item 58028
Table of Contents
Specifications ............................................. 2
Safety ......................................................... 3
Setup .......................................................... 7
Operation ................................................... 12
Maintenance .............................................. 17
Troubleshooting ......................................... 21
Parts Lists and Diagrams .......................... 24
Warranties ................................................. 30
Specifications
Pressure Washer Specifications
Pump Axial
Drive Direct
Maximum Pressure 3200 PSI
Flow Rate 2.8 GPM
Hose Length 25'
Wand Length 21"
Nozzles
Red: 0°
Yellow: 15°
Green: 25°
White: 40°
Black: Detergent
Engine Specifications
Displacement 223 cc
Engine Type
Horizontal Single Cylinder
4-stroke OHV
Cooling System Forced air cooled
Fuel
Type
87+ octane stabilizer treated
unleaded gasoline
Capacity 0.87 Gallon (3.3 Liter)
Engine Oil
Type SAE
10W-30 above 32° F
5W-30 at 32° F or below
Capacity 0.6 Quart (0.6 Liter)
Bore x Stroke 70 mm x 58 mm
Compression Ratio 8.5:1
Rotation viewed from PTO
(power takeoff - the output shaft)
Counterclockwise
Spark Plug
Type Torch
®
/LG
®
F6TC
Gap 0.0236" - 0.0315"
Valve Clearance
Intake 0.0039" - 0.0059"
Exhaust 0.0059" - 0.0078"
Speed
No Load 3800 RPM Max
Load 3500 RPM Max
The emissions control system for this Engine is warranted for standards set by the
U.S. Environmental Protection Agency. For warranty information, refer to the last pages of this manual.
