Page 15
For technical questions, please call 1-888-866-5797.
ITEM 59135
SAFETYOPERATIONMAINTENANCE SETUP
Nominal 12VDC Output
1. Move the Economy (ESC) Switch
to the OFF position.
2. Only use the 12VDC receptacle to
charge a 12 volt lead-acid type battery
using an appropriate charge controller.
(Battery and controller not included.)
The 12VDC output is not regulated.
3. Do not connect any device to the 12VDC
terminal that draws more than 8 amps.
4. If this 12VDC circuit protection is tripped,
reduce the load, and press
the Reset Button next to the outlet.
Reset
Button
12VDC
Receptacle
OFF
RUN
START
LOW OIL
OVERLOAD
OUTPUT
PARALLEL OUTLETS
RESET
AC 120V
RESET
DC 12V
ESC
THROTTLE
