Predator 59137 - Specifications

Page 2
For technical questions, please call 1-888-866-5797.
ITEM 59137
Table of Contents
Specifications ............................................................... 2
Safety ...........................................................................3
Setup ............................................................................8
Operation ..................................................................... 11
Maintenance ................................................................ 17
Troubleshooting ........................................................... 22
Parts List and Diagram ................................................ 25
Warranties ................................................................... 28
Specifications
Generator
Output
120 VAC, 60 Hz, 25 A, 1 Phase
12 VDC, 8 A (nominal)
3000 Running Watts
3500 Maximum Starting Watts
Receptacles
2 x NEMA #5-20 (3-prong, 120 VAC)
1 x NEMA #L5-30 (3-prong, 120 VAC)
1 x 12 VDC Two Pin Outlet
Displacement 212 cc
Compression Ratio 9.0:1
Engine Type
Horizontal Single Cylinder
4-stroke, OHV
Cooling System Forced air cooled
Fuel
Type
87+ octane, stabilizer-treated
unleaded gasoline
Capacity 2.33 Gallon / 8.80 Liter
Engine Oil
Type SAE 10W-30
Capacity 20 fl. oz.
Run Time @ 25% Load
with full tank
11 hr.
Sound Level at 23 feet, 25% load 56 dB(A)
Bore x Stroke 70 mm x 55 mm
Spark Plug
Type F6RTC (Torch) or equivalent
Gap 0.027"– 0.031"
Valve Clearance
Intake 0.002"– 0.003"
Exhaust 0.002"– 0.003"
Engine Speed 2600 – 3600 RPM
The emissions control system for this Engine is warranted for standards set by the
U.S. Environmental Protection Agency and by the California Air Resources Board (also known as CARB).
For warranty information, refer to the last pages of this manual.
