Page 26
For technical questions, please call 1-888-866-5797.
ITEM 59186
SAFETY OPERATION MAINTENANCESETUP
Engine Parts List
Part Description Qty.
1 Nut M5 5
2 Tube, Air Cleaner 1
3 Tube, Air Cleaner 1
4 Clip 2
5 Gasket, Air Cleaner 1
6 Carburetor Assy 1
7 Spark Eliminator 1
8 Stepper Motor 1
9 Cross Recessed Pan Head Bolt M3x8 1
10 Cross Recessed Pan
Head Bolt M3x12
3
11 Bolt M3x8 2
12 Gasket, Carburetor 1
13 Spacer, Carburetor 1
14 Nut M3 3
15 Bolt M5x12 8
16 Shroud, Left 1
17 Gasket, Inlet Tube 1
18 Bolt, Stud, Inlet 2
19 Tube, Breather 1
20 Starter Assy. 1
21 Shroud 1
22 Element, Air Cleaner 1
23 Cross Recessed Pan
Head Bolt St4.2x13
1
24 Bushing Ø10xØ5.5x12 1
25 Ignition Coil Support Plate 1
26 Bolt M5x30 1
27 Bolt M5x20 14
28 Bolt M6x12 6
29 Pulley, Starter 1
30 Bolt M6x16 2
31 Bracket, Starter 1
32 Fan, Recoil Starter 1
33 Nut M10 1
34 Rotor 1
35 Bolt M5x25 2
36 Stator 1
37 Bolt, Stud 2
38 The Trigger 1
39 Clip, Bolt 2
40 Clip, Fuel Line Ø9.5x0.8 2
41 Bolt, Stud 1
42 Seat, Crankcase 1
Part Description Qty.
43 Oil Seal 1
44 Tube, Fuel, Inlet 1
45 Switch Assembly, Oil Level 1
46 Hose 1
47 Seat, Oil Inlet 1
48 Wire Clip 1
49 Dipstick 1
50 Seal, Valve, In 1
51 Crankshaft Assembly 1
52 Shroud, Right 1
53 Bolt M6x40 2
54 Muffler Assy 1
55 Connecting Rod Assy 1
56 Pin, Piston 1
57 Clip, Piston 2
58 Piston 1
59 Scraper Ring Set, Piston 1
60 Gasket, Muffler 1
61 Hex Socket Head Cap Screw M5x20 2
62 Spring Washer Ø5 2
63 Crankcase 1
64 Pin, Dowel 2
65 Plate, Breather 1
66 Exhaust Pipe 1
67 Oil Filter Screen 1
68 Spark Plug 1
69 Pin, Dowel 2
70 Cover, Crankcase 1
71 Gasket, Exhaust 1
72 Governor Assembly 1
73 Cover Comp, Cylinder Head 1
74 Retainer, Spring 2
75 Camshaft Assembly 1
76 Flat Washer Ø5.2xØ12x0.4 2
77 Axle, Governor 2
78 Bushing Ø8.5xØ5.1x8.5 1
79 Shaft, Governor Arm 2
80 Rod, Push 2
81 Rocker Assy 2
82 Rocker Shaft 1
83 Valve, Intake 1
84 Valve Exhaust 1
85 Spring, Valve 2
86 Sound Deadening Mat 1
87 Empty Filter Housing 1
