For technical questions, please call 1-888-866-5797.
ITEM 59303
Table of Contents
Specifications ............................................................... 2
Safety ...........................................................................3
Setup ............................................................................8
Operation ..................................................................... 11
Maintenance ................................................................ 15
Troubleshooting ........................................................... 19
Parts Lists and Diagrams ............................................ 22
Warranties ...................................................................22
Specifications
Generator
Output
120 VAC, 60 Hz, 30.4 A, 1 Phase
5V 3.1A USB
3650 Running Watts
4550 Maximum Starting Watts
Receptacles
2 x NEMA #5-20 GFCI (3-prong, 120 VAC)
1 x NEMA #L5-30 (3-prong, 120 VAC)
2x USB-A Ports
Parallel Ports
Displacement 223 cc
Compression Ratio 8.5:1
Engine Type
Horizontal Single Cylinder
4-stroke, OHV
Cooling System Forced air cooled
Fuel
Type
87+ octane, stabilizer-treated
unleaded gasoline
Capacity 3.8 Gallons
Engine Oil
Type SAE 10W-30
Capacity 0.6 quart
Run Time @ 25% Load
with full tank, economy mode on
16.1 hr.
Sound Level at 23 feet, 25% load 64.6 dB(A) (economy mode on)
Bore x Stroke 70 mm x 58 mm
Spark Plug
Type F6RTC (Torch) or equivalent
Gap 0.028"– 0.031"
Valve Clearance
Intake 0.004"– 0.006"
Exhaust 0.006"– 0.008"
Engine Speed 2600 – 3700 RPM
The emissions control system for this Engine is warranted for standards set by the
U.S. Environmental Protection Agency. For warranty information, refer to the last pages of this manual.
