Table of Contents
Specifications ............................................. 2
Safety ......................................................... 3
Setup .......................................................... 7
Operation .................................................... 9
Maintenance .............................................. 12
Troubleshooting ......................................... 16
Warranties ................................................. 18
Parts Lists and Diagrams .......................... 20
Specifications
Maximum Bit Size 10″ Diameter x 39" Long
Drive Shaft 7/8″ Diameter x 1-7/8″ Long
Accessories
Spark Plug Wrench,
Screwdriver, 2 Hex Keys
Displacement 52cc
Engine Type
Vertical Single Cylinder
2-stroke
Cooling System Forced air cooled
Fuel
Type
87+ octane stabilizer-treated unleaded
gasoline
mixed with 2-cycle oil (see below)
Capacity 0.3 Gallon
Oil
Type
2-cycle oil (designed specifically
for mixing with gasoline)
Ratio
25:1 gasoline-to-oil ratio
5 fl-oz oil per gallon of gasoline
Run Time @ 50% Load
with full tank
1.3 hr.
Sound Level at 3 feet 102 dB
Bore x Stroke 44 mm x 34 mm
Compression Ratio 8.2:1
Rotation viewed from PTO
(power takeoff - the output shaft)
Clockwise
Spark Plug
Type
NGK
®
BM6A
Gap 0.0012"
Speed Idle 2700 RPM
The emissions control system for this Engine is warranted for standards set by the
U.S. Environmental Protection Agency. For warranty information, refer to the last pages of this manual.
