Predator 63022 - Parts Lists and Diagrams; Engine Parts List

Page 20 For technical questions, please call 1-888-866-5797. ITEM 63022
SAFETY SETUP OPERATION MAINTENANCE
Parts Lists and Diagrams
Engine Parts List
Part Description Qty.
1 Set Screw (M5 X 12) 1
2 Washer 1
3 Reel 1
4 Starter Rope 1
5 Spiral Spring 1
6 Recoil Starter Assy. 1
7 Starter Handle 1
8 Screw (M5 X 20) 4
9 Crankcase Gasket 1
10 Pulley 1
11 Oil Seal 1
12 Crankcase Cover 1
13 Crankcase Gasket 1
14 Ball Bearing 1
15 Crankshaft (Complete) 1
16 Woodruff Key 1
17 Ball Bearing 1
18 Set Pin 1
19 Crankcase 1
20 Small Oil Seal 1
21 Screw 7
22 Fly Wheel 1
23 Nut 1
24 Screw 2
25 Flameout Line 1
26 Motor 1
27 Washer 2
28 Spring 1
29 Clutch 1
30 Washer 2
31 Screw 2
32 Fan Shroud 3
33 Washer (B) 2
34 Screw 2
35 Piston Pin Circlip 1
36 Jump Ring 2
37 Piston Pin 1
38 Piston 1
39 Piston Ring 2
Part Description Qty.
40 Cyclinder Gasket 1
41 Cylinder 1
42 Screw 4
43 Cylinder Cover 1
44 Spark Plug 1
45 Spark Plug Clip Reed 1
46 Spark Plug Cover 2
47 Spark Plug Cap 1
48 Head Cover 1
49 Screw 1
50 Muffler Insulator 1
51 Muffler 1
52 Stud 2
53 Socket Head Bolt 1
54 Muffler Protection Cover 1
55 Socket Head Bolt 1
56 Intake Gasket 1
57 Intake 1
58 Screw 2
59 Carburetor Gasket 1
60 Carburetor Assy. 1
61 Air Cleaner Case 1
62 Self Tapping Bolt 1
63 Air Filter 1
64 Air Filter Cover 1
65 Head Cover Bolt 1
66 Power Switch 1
67 Plastic Part 1
68 Block Rubber 1
69 Fuel Filter 1
70 Fuel Line 1
71 Fuel Line Plug 1
72 Bolt 4
73 Fuel Tank 1
74 Fuel Tank Cover 1
75 Intake Strut 1
76 Intake 1
77 Fuel Cap 1
Record Product’s Serial Number Here:
Note: If product has no serial number,
record month and year of purchase instead.
Note: Some parts are listed and shown for
illustration purposes only, and are not available
individually as replacement parts.
