11. Specications
PES017 48V
Over all dimension 1099L X 598W X 1021H*
Foot step height 160mm*
handlebar height 987mm*
Maximum permissible mass 100 Kg*
Gross weight 34.9 Kg*
Net weight 24.5 Kg
Wheelbase 840mm*
Ground clearance 135mm*
Front suspension type 260mm Oil damper telescope
Front fork tube diameter 27mm
Rear suspension type Spring mono shock 125mm
Swingarm GB Q235 carbon structural steel
Frame GB Q235 carbon structural steel
Front brake Single action 140mm disk brake
Rear brake Dual action 140mm disk brake
Front tyre 10X2.5 36PSI
Rear tyre 10X2.5 36PSI
Motor nominal power 350W
Motor peak power output
(fully charged battery) 960W
Efciency >78%
Motor torque 40Nm
System voltage 48V
Battery model /capacity BL522/48V/10.5Ah
Battery cells
LG/SAMSUNG/Panasonic
Li-ion 18650
Front light StVZO, ISO6742, CE, Rohs, RKF, 30LUX
Rear light LED tail light
Control unit / Speed limited switch Lcd / back light / mode selector / thumb throttle
Charger AC100-240V DC54.6V/2A
Endurance** Range>25Km@80kg use 10.5Ah battery pack**
Max. speed*** 25Km/hr***
weighted emission
sound pressure level <70db
*. Weight, Dimensions may change with different features, subject to change without further notice.
**. Endurance test is based on 80 Kg loading, cruising and non stop riding with ECO mode speed on
hard concrete oor with zero wind speed.
***. Speed may vary by different country.
**** battery capacity might changes according to sales region, changes without further notice.
(Dimensions and specications may vary with features, options and accessories)
