Predator PH16-71 - LCD Panel Removal

1-32 Disassembly Procedures
LCD Panel Removal 0
Prerequisite:
LCD Bezel Removal
NOTE:
NOTE:
The eDP cable includes the LCD panel cable and the camera cable.
1. Unroute and detach the eDP cable from the cable guides on LCD cover as shown in
Figure 1-45.
Figure 1-44. LCD Panel Removal
