Flat Panel
Griplate™ Washer
Nylon Spacer
Mounting Bracket
Mount Point
Mounting Screw
M6 x 6mm screw
Triple Mount Structure
Eliptical Tilt Mount
4
5
Attach the eliptical tilt mount using four(4) M6 x 6mmscrews
Premier Mounts’ nylon spacers allow you to attach the mounting
bracket to at panels which have recessed or uneven mount points.
Each nylon spacer will add distance between the mounting bracket
and your at panel.
The nylon spacers must only be installed between the mounting
bracket and your at panel.
The nylon spacers will t M4, M5, M6 and M8 screw sizes.
