PREMIER MANUFACTURING COMPANY
Page 5
SAFETY WARNING
This product is designed for towing under
normal conditions within the stated gross
trailer weight. Do not overload or abuse this
product. Overloading or abuse may lead to
property damage, severe injury, or death.
200 / 200L / 300 Bolt-On Drawbar Eyes
200 STANDARD INSTALLATION DRAWING
SPECIFICATIONS AND LOAD CAPACITIES
200L STANDARD INSTALLATION DRAWING
Inside Diameter:
Unit Weight:
2 3/8 in. (60 mm)
16 lbs. (7.3 kg)
Max. Gross Trailer Weight:
Maximum Tongue Weight:
100,000 lbs. (45,359 kg)
15,000 lbs. (6,803 kg)
Inside Diameter:
Unit Weight:
2 3/8 in. (60 mm)
19.1 lbs. (8.7 kg)
300 STANDARD INSTALLATION DRAWING
Inside Diameter:
Unit Weight:
3 in. (76 mm)
19.5 lbs. (8.9 kg)
