1-800-255-5387 • www.premier-mfg.com
premier manufacturing company
Page 4
Direction of view
for assembly
Mounting
base
Top of
coupling
Bottom of
coupling
IMAGE #2
IMAGE REFERENCE SECTION
44-62:
297:
373B:
388:
2071:
2072:
2072A:
2072B:
2073:
Snap Ring (2)
Locknut
Spacer
Pin
Bolt
Latch
Spring
Bushing
Latch Lock
2073A:
2073B:
*266:
*271:
*274:
*274A:
*279:
**2075:
**44-62:
**2074:
**373B:
Spring
Bushing
Spring
Thimble
Bolt
Locknut
Shoe
Handle
Snap Ring (2)
Pin
Spacer
*Not included in parts kit, available individually.
**Available as a separate kit (2075K).
**44-62
2071
2072B
2072A
2073
2073A
2073B
373B
*271
*266
2072
297
44-62
388
44-62
*279
*274
*274A
**2075
**2074
**373B
**44-62
2000PK Parts Kit Includes:
*271
*379
*376
*374
*274A
IMAGE #1
Front of
379 Shoe
*271:
*274A:
*374:
*376:
*379:
Thimble
Locknut
Bolt
Spring
Shoe
2300B Shoe components:
WARNING:
Do NOT bind-up (jackknife) any application, as
stresses can cause damage to the hitch, drawbar
eye, other components or any combination of
them. Jackknifing may result in failure of products
or components, resulting in detachment of the
trailer while in use.
