Premier SAK600BP - Page 17

PORCELAIN BACKGUARD
THERMOPLASTIC END CAP BACKGUARD
FASTENERS REQUIRED
B-
#10-24 X .75”
Phillips Pan Hd
screw
A-
#8 X 1/2” Phillips
Countersink Hd
screw
C-
#10-24 X 3/8”
Phillips Truss Hd
bolt
D-
#10-24 Hex Keps
Nut
A
A
B
B
C
D
BACKGUARD
SUPPORT
MAIN TOP
BACKGUARD
FLUE BOX
BACKGUARD MAIN TOP
A
A
A
B
B
A-
#10-24 X 3/8”
Phillips Truss Hd
bolt
B
#10-24 Hex Keps
Nut
FASTENERS REQUIRED
B
B-
#10-24 Hex Keps
Nut
A-
#10-24 X 3/8”
Phillips Truss Hd
bolt
FASTENERS REQUIRED
VENT RAIL BACKGUARD
15
A
B
B
C
D
MAIN TOP
A
A
B B
B
VENT RAIL
A
A
B
B
