PAC-M200-A Interface Module for PremiSys
®
Air Products2
PAC-M200-A M-NET Wiring
Table of Contents
Replacing PAC-M200-A Interface Module ......1
PAC-M200-A M-NET Cable Specification ......1
PAC-M200-A M-NET Wiring ..................2
Interface Module Replacement ..............3
Replacing PAC-M100-A with PAC-M200-A ......4
PAC-M100-A M-NET Cable Specification ......4
M-NET Wiring ..............................5
PAC-M100-A Replacement ..................5
M-NET Address Setting .....................6
CITY MULTI
®
System and PremiSys
®
One CITY MULTI
®
and One PremiSys
®
.........7
One CITY MULTI
®
and Two PremiSys
®
.........7
Two CITY MULTI
®
and One PremiSys
®
.........7
Outdoor Reset Function .....................8
Control Methods ...........................9
Memo ............................... 10 & 11
Back Cover ...............................12
Figure 1. PAC-M200-A M-NET Wiring
OUTDOOR AIR
WEATHERHOOD
SUPPLY BLOWER
ACCESS DOOR
COIL / ELECTRIC HEATER
ACCESS DOOR
FILTER
ACCESS DOOR
ELECTRICAL
ACCESS DOOR
EXHAUST BLOWER
ACCESS DOOR
WHEEL
ACCESS DOOR
ACCESS DOOR
OPTIONAL
UNIT DISCONNECT
HIGH VOLTAGE
FIELD WIRING
LOW VOLTAGE
FIELD WIRING
Door #1
Interface Module
PAC-M200-A located
behind door #1
