Step 1:
To install the power cord, insert the female end of
the power cord into the Power Cord Socket
located on the rear of the tensioner and plug the
male end into a grounded power outlet.
Step 2:
Turn the main power switch on by pressing it in
I direction. (O direction is to turn the tensioner
off.) and the red power indicator light will light
up on the panel. Voltage between 220V and
240V (50 Hz to 60 Hz) is acceptable. NOTE: A
2 amp spare fuse is located in the power cord
receptacle.
Step 3:
Select the KG unit by pushing switch of KG/LB
up and the KG indicator light will light up.
Step 4:
Select the LB unit by pushing switch of KG/LB
down and the LB indicator light will light up.
