INSTALLATION
The machine is shipped in two cartons, a carton for the tension head and a carton for
the racquet mount and accessories.
Step 1:
Open the carton of the tension head.
Carefully lift the tension head assembly
out of carton and place it on a hard surface
or table.
Step 2:
Remove the 4 Allen bolts from the bearing pivot of the tension head assembly by
a 5 mm wrench.
Step 3:
Open the carton of the racquet mount.
Carefully lift the racquet mount assembly
out of carton and place its turntable in the
bearing pivot of the tension head assembly.
Next insert the 4 Allen bolts in the 4 holes
of the turntable and then tighten them
evenly with a 5 mm wrench.
