OVERVIEW
6
48V Phantom Power. Each channel of the DigiMax has 48V
Phantom power available. When the Phantom power switch is
engaged, power is supplied at a constant rate. This assures
optimum performance of your condenser microphone(s) and
that it will be free of distortion associated with insufficient power.
This switch is located on the back panel adjacent to the XLR
input.
Phase Reverse Switch. A phase reverse switch is provided on
channels One and Two. This switch enables the user to invert
the phase of a microphone when phase cancellation is noted.
The phase reverse switch allows the operator to avoid phase
cancellation when identical microphones are used in close
proximity to one another. The phase reverse switch also can
compensate for different XLR connector hook-ups where pin
connections have been inverted.
-20 dB Pad. A -20 dB pad is available on each channel of the
DigiMax for reducing in-coming signal levels to the unit. Using
this pad can provide a more manageable signal from high
output devices giving the operator greater control over the in-
coming signal and a much reduced chance of over-driving the
input and thereby avoiding distortion.
Enhance. The Digimax provides an EQ Enhancement feature
on each channel. Engaging this switch gives the processed
signal a cut of 3 dB between 250 Hz and 5kHz. This has a
smoothing effect on mid-range heavy signals and gives a flatter
response characteristic.
Sample Rate Selector. The Digimax has a switch on the front
panel that lets the operator choose the sample rate. It provides
selectable rates of 32k, 44.1k and 48k.
EXT CLOCK. When the External clock switch is engaged the
Digimax goes into “chase” mode and automatically recognizes
