7 ELECTRICAL SYSTEM
7.1 GENERAL INFORMATION ABOUT THE ELECTRICAL SYSTEM
Reference Designation
1 Battery switch control, DC breakers, Touch screen, Service batteries
2 Switches / DC breakers
3 Power unit (Power distributor, Fuses, Relay box, Battery switch)
4 Bow thruster batteries
5 Batteries - Generator & Motor
6 Battery charger
- The risks of fire or explosion may result from careless use of the DC and
AC systems.
- The risks of electrocution may result from careless use of the AC system.
7
DC INSTALLATION
