69/118
REF Designation
21 Grouping N°1 of circuit breaker controls
22 Control of circuit breaker - Navigation lights
23 Control of circuit breaker - Mooring light
24 Control of circuit breaker - Deck searchlight
25 Control of circuit breaker - Instrument lighting
26 Control of circuit breaker - Lighting
27 Control of circuit breaker - Comfort onboard
28 Grouping N°2 of circuit breaker controls
29 Control of circuit breaker - Bilge pumps
30 Control of circuit breaker - Water unit
31 Control of circuit breaker - Electric windlass control
32 Control of circuit breaker - Navigation instrument
33 Control of circuit breaker - Auto pilot
34 Available
35 Set N° 1 of switches in wheelhouse
36 Switch - Horn
37 Switch - Wiper - Starboard
38 Switch - Wiper - Port side
39 Switch - Windscreen washer
40 Switch - Demister (2 speeds)
41 Available
42 Set N° 2 of switches in wheelhouse
43 Switch - Bilge pump - aft (manual)
44 Switch - Bilge pump - forward/Central (manual)
45 Switch - Fuel gauge
46 Switch - Windlass (upward and downward motion)
47 Available
48 Available
77 Switch grouping - Flying bridge
78 Switch - Horn
79 Switch - Windlass - (upward and downward motion)
80 Available
100 House switching block
101 Switching card A + Details per card of the position:
• of the configuration jumpers
• of the wires of the circuit breaker controls
• of the return wires of the switch indicator lights
102 Switching card B + Details per card of the position
103 Switching card C + Details per card of the position
104 Switching card D + Details per card of the position
105 Switching card E + Details per card of the positionn
106 Switching card F + Details per card of the position
