128-9364

4 of 28

2 Pin Door Lock Output Harness #1122242

4 Pin 2nd Main Harness #1124301

4 Pin Shock Sensor Harness #1122591

6 Pin Antenna Harness #1124325

1 Black Chassis Ground

2 White/Red Parking Light Relay Input

3 White/Black (+) Siren Output

4 White Parking Light Relay Output

1 Red (-) Door Lock Output

2 Green (-) Door Unlock Output

1 Blue Predetect

2 Green Full Trigger

3 Black Chassis Ground

4 Red + 12 Volts

1 Red + 5 VDC

2 Green RX

3 Black Ground

4 Blue TX

5 Gray Valet Enable

6 Blue LED Cathode
