5-32 Other Features
PA-1619 Owner's Manual H3-45 VIP
PROGRAMMING TRANSMITTERS
Up to 20 transmitters can be used with the keyless
entry system. To add or replace transmitters, the
system must be first put into learn mode using the
vehicle keypad.
To program transmitters perform the following
steps:
l Hold the 5/6 button of the keypad for 5
seconds (keypad will start to beep and flash).
l Enter the vehicle factory six (6) digit authority
code.
l Hold button 7/8 for 5 seconds, a double beep
will play, confirming that the system is now in
learn mode.
l Press the lock button on each transmitter to
be programmed for 5 seconds with a two
seconds pause between each transmitter.
l Press the 9/0 button twice to exit learn mode
(the keypad will beep twice and stop
flashing).
NOTE
If more than 20 transmitters are programmed,
additional transmitters will over- write the first
ones.
SLIDE-OUT OPERATION
H3-45 VIP vehicles can accommodate up to 4
slide-out units. Slide-out units located in the front
right (front curb side) position have a mobile floor
system creating a flush floor at room extension.
Due to the high current demand and safety
requirements of the slide- out system, room
operation is on a "first in first served" basis,
meaning only one slide-out unit may be operated at
a time.
SAFETY PRECAUTIONS
Before operating both slide-out units, proceed to
the following verifications:
l Make sure that the area outside of the slide-
out is clear and that there are no persons or
objects within 3 feet of the slide-out outside
wall. Serious personal injury or damage to the
vehicle components may occur.
l Make sure that the area inside the motor
home where the room retracts (30" for the
front and 24" for the rear slide-out) is free of
people or obstacles. Serious personal injury
or damage to the vehicle components may
occur.
l For slide- out units with flush floor option,
make sure there are no objects or persons on
the floor during operation.
l In temperatures below freezing point, make
sure that the entire sliding surface outside the
slide-out is free of snow, ice or sleet. Failure
to clear all ice or snow may seriously damage
the inflatable seal.
l The parking brake must be applied.
l The transmission must be in the "NEUTRAL"
position.
l Open a window to avoid slide-out movement
restriction.
l Level the vehicle.
FRONT AND REAR SLIDE-OUT OPERATION
Before extending or retracting the slide-out, please
make sure all the following conditions are met:
1. Make sure the air pressure is 110 psi
minimum on the auxiliary air pressure gauge.
2. Make sure the parking brake is applied and
that transmission is in the "NEUTRAL"
position.
3. Turn the ignition key to the "ON" position,
start the engine and set the RPM to fast idle.
CAUTION
Before extending or retracting the slide-out, always
open a window to avoid movement restriction and
to prevent the motor from stopping in overcurrent
because of a vacuum or pressure build up inside
the vehicle.
