PROCEDURE NO: SAV060034 REVISION 4
Page 10 of 15
Location: front electrical compartment
Disconnect I/O A, I/O B, ABS, master ID, CECM and
CPC modules and also disconnect connector C92
Disconnect the 3 connectors
from the I/O B and I/O A modules
Disconnect the 2 connectors from the ABS
module
2.20
Disconnect CPC connectors
Disconnect connector from master ID
To Next Page
