PREVOST XL-45 - CONTROLS AND INSTRUMENT PANELS

CONTROLS/INSTRUMENTS
2
-
3
CONTROLS AND INSTRUMENT PANELS
FIGURE 5
18114A
No. Panel Pg. No. Panel Pg.
1 L.H. Side Control Panel 2-4 5 Detroit Diesel PRODRIVER
TM
Controls
2-20
2 L.H. Lower Switch Panel 2-14 6 R.H. Console 2-15
3
Dashboard (without Tachograph)
Dashboard (with Tachograph)
2-7
2-8
7 R.H. Lateral Console 2-22
4 R.H. Lower Switch Panel 2-15
